Kawasaki FR730V-S00 24 HP Vertical 1" X 3-5/32" Shaft

Price: $2,264.00
Sale Price: $1,836.00
No reviews yet Write a Review
SKU:
FR730V-S00
Availability:
‎Free 1–5 day delivery! NO TAX (except MI).
Weight:
105.00 LBS

Please note: If purchasing an engine, free shipping
does
not apply to CA, WA, AZ, OR, and NV.
Please contact us for details prior to checkout. Thank you.

Prop. 65 Warning: This product contains chemicals known to the state of California to cause cancer and birth defects, or other reproductive harm.

  • FREE SHIPPING

  • ZERO SALES TAX

  • LOWEST PRICES

  • WIDEST SELECTION

Kawasaki FR730V-S00 24 HP Vertical Shaft Engine delivers reliable 726cc V-Twin gasoline power for compatible riding lawn mowers, zero-turn mowers, and replacement engine applications.

Featuring a 1-inch diameter x 3-5/32-inch long vertical crankshaft , electric start, and a 15-amp charging system, this Kawasaki FR-series engine is built for equipment requiring this specific shaft configuration.

Available through Carroll Stream Motor Company, supplying replacement engines and power equipment solutions since 2005.

24 HP 726cc Kawasaki V-Twin
1" x 3-5/32" Vertical Crankshaft
Electric Start 15-Amp Charging System

Kawasaki FR730V-S00 24 HP Replacement Engine

The Kawasaki FR730V-S00 is a 24 horsepower, 726cc, four-stroke OHV V-Twin engine designed for compatible lawn tractors, riding lawn mowers, and zero-turn mowing equipment.

This engine features a 1-inch straight keyed vertical shaft measuring 3-5/32 inches long. The crankshaft configuration is especially important when replacing an existing engine, because pulley alignment, deck-drive compatibility, and engine mounting requirements vary by equipment model.

Built with cast-iron cylinder liners, electronic ignition, automatic compression release, and a full-pressure lubrication system with an oil filter, the FR730V engine platform is designed to provide dependable performance with proper installation and regular maintenance.

Whether you are replacing a worn-out Kawasaki engine or maintaining compatible outdoor power equipment, the FR730V-S00 offers an established Kawasaki engine configuration with accessible service and replacement components.

Kawasaki FR730V-S00 Engine Features

  • 24 HP Engine: 726cc displacement with a 90-degree V-Twin OHV configuration.
  • Vertical Shaft Design: 1-inch diameter and 3-5/32-inch total crankshaft length.
  • Electric Start: Electric starter with automatic compression release.
  • 15-Amp Charging System: Provides charging output for compatible equipment.
  • Pressurized Lubrication: Full-pressure lubrication system with a replaceable oil filter.
  • Forced-Air Cooling: Engine cooling system featuring a rotating grass screen.
  • Durable Construction: Cast-iron cylinder liners and mechanical governor.
  • Serviceable Design: Engine components and replacement parts are available for regular maintenance and repairs.

Kawasaki FR730V-S00 Technical Specifications

Manufacturer Kawasaki
Model / SKU FR730V-S00
Engine Series Kawasaki FR
Horsepower 24 HP at 3,600 RPM
Displacement 726cc
Engine Type 4-Stroke OHV V-Twin
Bore x Stroke 3.1" x 3.0"
Shaft Orientation Vertical
Shaft Diameter 1 inch
Shaft Length 3-5/32 inches
Shaft Type Straight Keyed
Keyway 1/4 inch
Starting System Electric Start
Charging Coil 15 Amp
Fuel Type Unleaded Gasoline
Engine Cooling Forced-Air Cooled
Lubrication Pressurized With Oil Filter
Oil Capacity 2.2 US Quarts
Mounting Pattern 4-Bolt
Dry Engine Weight Approximately 89 lbs.
Muffler Included No
Fuel Tank Included No
Warranty 3-Year Consumer and Commercial, subject to manufacturer terms

Confirm Kawasaki FR730V-S00 Replacement Compatibility

Before ordering a Kawasaki FR730V-S00 replacement engine, verify your existing engine specification and equipment installation requirements.

  1. Find the Engine Model: Locate the Kawasaki identification label and record the complete model and specification number.
  2. Check Shaft Dimensions: Confirm a 1-inch shaft diameter and 3-5/32-inch shaft length, including keyway requirements.
  3. Compare Mounting: Verify mounting-hole locations, crankshaft position, and available engine clearance.
  4. Check Electrical Compatibility: Compare the starter, charging system, and wiring connections.
  5. Review Engine Accessories: Confirm muffler, throttle, choke, fuel connections, and any existing equipment-specific components.
Important: Kawasaki FR730V engine configurations are not necessarily interchangeable. Even engines with the same horsepower may have different shaft lengths, mounting configurations, and electrical connections.

Kawasaki FR730V-S00 Replacement Model References

The following Kawasaki FR730V specifications are listed as potential cross-references. Confirm your original engine and mower specifications before purchasing.

FR730V-AS00, FR730V-BS00, FR730V-CS00, FR730V-DS00, FR730V-ES00, FR730V-FS00, FR730V-FS00S, FR730V-S05, FR730V-AS05, FR730V-BS05, FR730V-CS05, FR730V-DS05, FR730V-S07, FR730V-AS07, FR730V-BS07, FR730V-CS07, FR730V-S08, FR730V-S09, FR730V-AS09, FR730V-BS09, FR730V-CS09, FR730V-DS09, FR730V-S10, FR730V-AS10, FR730V-BS10, FR730V-CS10, FR730V-S11, FR730V-AS11, FR730V-BS11, FR730V-S12, FR730V-AS12, FR730V-BS12, FR730V-S13, FR730V-AS13, FR730V-BS13, FR730V-S15, FR730V-AS15, FR730V-BS15, FR730V-S18, FR730V-AS18, FR730V-S19, FR730V-AS19, FR730V-S20.

Cross-reference disclaimer: Model references are provided as a courtesy and do not guarantee direct replacement compatibility. Additional components or installation modifications may be required.

For fitment assistance, contact Carroll Stream Motor Company at 888-208-2088 with your original engine model and equipment information.

Kawasaki FR730V-S00 Frequently Asked Questions

What size crankshaft does the FR730V-S00 have?

The FR730V-S00 has a 1-inch diameter vertical crankshaft with a total length of 3-5/32 inches. Verify the keyway and installation requirements before ordering.

Is the Kawasaki FR730V-S00 a 24 HP engine?

Yes. The FR730V-S00 is rated at 24 HP and features a 726cc, four-stroke V-Twin engine configuration.

Will the FR730V-S00 fit my zero-turn mower?

It may fit compatible zero-turn mowers and riding lawn tractors. Confirm the original engine model, crankshaft dimensions, mounting, electrical connections, and equipment-specific components.

Does this engine include a muffler?

No. The listed FR730V-S00 configuration does not include a muffler or fuel tank. Verify accessory requirements before installation.

Is the FR730V-S00 air-cooled?

Yes. The Kawasaki FR730V-S00 uses a forced-air cooling system. It is not a liquid-cooled engine.

What is the difference between the FR730V-S00 and FR730V-S16?

The FR730V-S00 has a 1-inch diameter, 3-5/32-inch long shaft. The FR730V-S16 uses a larger 1-1/8-inch diameter, 4-9/32-inch long shaft. These specifications are not directly interchangeable without verifying equipment compatibility.

Compare Related Kawasaki Engines

Shop Kawasaki FR730V-S00 at Carroll Stream

Carroll Stream Motor Company has supplied replacement engines and outdoor power equipment solutions since 2005.

If you're unsure whether the FR730V-S00 is the correct engine for your equipment, our team can help review your model and replacement requirements.

Kawasaki FR730V-S00 | 24 HP | 726cc | 1" x 3-5/32" Vertical Shaft
