CS177ESH Electric Start 9HP 270cc Engine by Carroll Stream Motor Company
Keyed - Straight 1" Diameter, 1/4" Shaft
The highest quality guaranteed! We have been in business since 2005, and our engines are fully rebuildable with all parts available. We are ready to answer your questions right away. We also have a phone number where a professional can answer your questions at 248-628-4638 or 888-208-2088. Don't make a mistake and buy from a fly by night company with ZERO after-sales support.The Small Gas Engines from Carroll Stream are perfect for industrial, commercial and residential applications. Your order ships quickly with expert turnaround time in our fully stocked warehouse. Packaged with care, Carroll Stream Motor Company provides free shipping. In-Stock! Fast and Free Shipping! The CS177ESH motor is a 4 stroke OHV single cylinder with 11.4 ft. lbs. of gross torque.
CS177ESH by Carroll Stream Motor Company is a 9HP engine. This recoil pull start is perfect for mixers, or any other application where 6:1 gear reduction for small engine reduction is needed. Highest quality 9 HP electric start motor.
Built with quality components and is ready to outlast the competition. Purchase now to take advantage of our free shipping and quick turnaround time. Or, call if you have questions! 888-208-2088, 248-628-4638. No sales to California.
| Specifications | |
|---|---|
| Make | Carroll Stream Motor Company |
| Model | CS177ESH - 9HP Electric Start and Recoil |
| Type | Small Engine |
| Fuel | Gas Unleaded 86 Octane or Higher |
| Engine Type | 4 Stroke OHV Single Cylinder |
| Bore/Stroke | 77 X 58 |
| Displacement | 270 cc |
| Compression Ratio | 8:2:1 |
| Max Power | 9 HP @ 3600 RPM |
| Max Torque | 11.4 ft. lbs. @ 2500 RPM |
| Ignition Type | TCI No Contact Transistorized |
| Dimensions (L x W x H) | 15 x 19 x 17 in. |
| Starting Type | Electric Start and Recoil Pull Start |
| Fuel Tank Capacity | 1.58 Gal. |
| Dry Engine Weight | 60 lbs. |
| Shaft Type | Keyed - Straight |
| Shaft Diameter | 1" Diameter, 1/4" Keyway |
| Shaft Length | 3-1/2" Total, 2-7/8" Usable |
| Shaft I.D. Thread Size | 7/16"-20 Drilled and Tapped |
| Bolt Pattern | 4 Bolt |
| Oil System | Splash |
| Reduction Type | 6:1 Gear Reduction |
| Engine Cooling Type | Forced Air Cooling |
| Features | |
| Cast Iron Sleeve | |
| 4 Stroke OHV Small Engine | |
| Large Fuel Tank | |
| Cross Reference Guide | |
| Honda: GX 270 QAE | |
| Kohler: CS10T | |
| Briggs & Stratton: 185432-0247 | |
| Accessories | |
| Spark Plug Wrench | |
| User Manual | |
Summary of the 9hp Small Gas Engine
Carroll Stream Motor Company upholds a commitment to excellence as our norm. With a history dating back to 2005, we have accumulated more than 15 years of expertise in the industry, allowing us to provide engines that can be completely rebuilt using easily accessible parts. Opt for a reputable brand that backs its products with unparalleled post-sales assistance, rather than settling for inferior alternatives.
The CS177ESH is ideal for a diverse array of industrial, commercial, and residential uses. Whether it's mixers or other equipment that needs a 6:1 gear reduction, this motor offers reliable performance and durability, making sure you can complete the task effortlessly. With its strong 9HP output and substantial torque, it is well-suited for challenging jobs, delivering the necessary power when required.
The CS177ESH is designed with both electric start and recoil pull start options, providing effortless equipment starting. Whether you favor the convenience of electric start or the reliability of recoil pull start, this engine offers flexibility, making it simple to tackle any task with confidence. Its large fuel tank and cast iron sleeve further enhance durability and operational efficiency.
Our team of experts is available to support you throughout the entire process. We guarantee timely answers to your questions and expert advice, ensuring that you are equipped with all the necessary information to make well-informed decisions. Enjoy a stress-free shopping experience with our fast processing and complimentary shipping. Thanks to our well-supplied warehouse, your purchase will be dispatched promptly, guaranteeing minimal delays and optimal efficiency. Count on our dedication to customer contentment for a smooth and effective transaction.
The Carroll Stream CS177ESH Electric Start 9HP 270cc Engine offers a combination of reliability, power, and convenience, making it an excellent choice for a wide range of uses. Its sturdy build, simple starting features, and strong support make it a valuable asset to your equipment collection.
